240sqm/h konica 512i wide format digital inkjet vinyl banner printing machine plotter
- Description
- Inquiry
Description
240sqm/h konica 512i wide format digital inkjet vinyl banner printing machine plotter
the advantage of wide format printer :
1. Latest Industrial-grade Konica Printhead
Newest Konica Minolta 512i or 1024i print heads, with much wider nozzles, and latest technology,
more efficient, faster printing.
2. Excellent Machine Frame Work
Specially designed left and right steel side boards for TC-3308L, thickness 8mm, weight 27kgs, bending for
TC-3308L, thickness 8mm, weight 27kgs, bending resist rate is up to 235MPa. It enables machine body bear
for maximum 2 tons weight, so as to effectively resist vibration when the carriage is moving fast, make sure
each ink dot drops accurately.
3.Strong Aluminum Beam and THK Rail
Adopt the strong aluminum beam and THK rail; longtime use in printing and head carrier moves steadily
and quietly. The German IGUS chain has been certified with its quality.
4.Infrared heating system and drying fan
Infrared heating system and drying fan can satisfy the large printing output.
5.Feeding Up Gear Protective Cover
Feeding up gear protective cover, which protect the operator or engineer from the risk of hurt.
6.Imported Panasonic AC servo motor
Imported 400W Panasonic AC servo motor system, the powerful motor can keep the
printing work for long time.
7.Multiple 3 Phases Constant Heating System:
Multiple 3 phases constant heating system promotes ink absorption of material, which makes printing
clearer, dry faster and image stay for longer.
the paraments of vinyl banner printing machine :
| Model | TC-3304I | TC-3308I | |
| Print Head | Drop on demand Piezo Head | ||
| Number of Printhead | 4 Heads | 8 heads | |
| Maximun Print Width | 3200mm(125.98″) | ||
| KM512-30pl printhead (4head or 8 heads) konica 512i large format printer | 480*360dpi 2pass 240m2/h | 480X360dpi 2pass 480 m2/h | |
| 480*540dpi 3pass 180m2/h | 480X540dpi 3pass 360 m2/h | ||
| 480*720dpi 4pass 120m2/h | 480X720dpi 4pass 240 m2/h | ||
| Media | max.width | 3300mm(129.92″) | |
| Max. Weight | 80kg | ||
| Type | Frontlit,Backlit,Vinyl,Polyester,Window Film, Leater… | ||
| thickness | 4mm(Max) | ||
| Heating System | 3 way intelligent heater | ||
| Auto Media Feeding &Take-up System | Equipped | ||
| Ink | Type | Solvent ink (C,M,Y,K) | |
| Capacity | k1L or 5L per Color Main Tan | ||
| Auto Cleaning System | Positive Pressure Cleaning,Anti-Clogging Flash Function&Capping System | ||
| Print interface | USB2.0 | ||
| Power Specification | 220V/230V 50Hz/60Hz Printer:660W Heater:1900W | ||
| Operational Environment | Temperature:20°C-28°C Humidity:40%-70% | ||
| Compatible RIP Software | Photoprint,UltraPrint,Topaz,Wasatch,Caldera,Maitop | ||
| Dimension &Weight | Machine | L4800mm×W1110mm×H1450mm 570kg | L4800mm×W1110mm×H1500mm 800kg |
| Package | L4800mm×W1030mm×H880mm 620kg
| L4800mm×W1030mm×H1580mm 950kg
| |
Wide range of application industries:
why we chose our Acetek digital inkjet printing machine?
1. Our company establish in 2007, with 8years of printer export experience.
2. With full experience, we know printer well, we can provide you professional solution
3. 10 Engineers with full printer skill, and they are english speaking, communicate free.
Engineer online 24hours, solve your daily work problem intime.Engineer can come to serive,
also welcome your engineer visit us for free traning.
4. New model always showing in our showroom, welcome your visit for check and printing
sample.
5. We have enough stock in warehouse, ensure fast shipment
